E003M6 M Spiral Flute 45deg M6
| Thread Diameter Size (TDZ) | M6 | Applicable Material | Steel | Stainless Steel |
| Thread Pitch (TP) | 1 mm | Cutting Edge Material | HSSPM |
| Thread Standard | Metric | Thread Tolerance Class (TCTR) | 6H |
| Overall Length (OAL) | 67.3 mm | Standard | ISO529 |
| Thread Cutting Part Length (THL) | 10 mm | Flute Type | Spiral |
| Usable Length (LU) | 27 mm | Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 6.3 mm | Coolant Supply Property (CSP) | External |
| Flute Count (NOF) | 3 | Measurement Type | Metric |
| Flute Helix Angle (FHA) | 45 Degrees |
Product Features
| Country of Origin | SE |
Shipping Info
Package Weight
.2500
